23
07610-004-92-22-A
ELECTRICAL BOX
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Cover, Electrical Box 05700-004-85-07
2 11 Nut, 10-32 Hex 05310-004-40-48
3 1 Decal, Warning-Disconnect Power 09905-100-75-93
4 2 Washer, Flat 05311-173-01-00
5 2 Screw, 10-32 x 3/4" 05305-011-62-17
6 1 Ground Lug 05940-200-76-00
7 9 Screw, 10-32 x 1/2" 05306-004-42-04
8 1 Fitting, 1/2" Straight 05975-003-33-27
9 1 Thermostat, High-limit 05930-004-33-12
10 1 Bracket, High-limit 05700-004-36-37
11 1 Decal, Ground 09905-011-86-86
12 1 Decal, L1 L2 L3 09905-004-37-05
13 2 Fitting, 90-degree, 3/4" 05975-004-19-42
14 1 Conduit, 1/2" PVC Flex 05975-003-77-47
15 2 Nut, Conduit Black Nylon, 3/4" 05975-003-81-29
16 1 Fitting 05975-011-65-51
17 2 Screw, 6-32 x 3/8” 05305-002-25-91
18 1 Terminal Block, 3-pole 05940-011-48-27
19 1 Contactor, 30 A, 240 VAC 05945-002-74-20
20 2 Contactor, Heater, 4-pole, 35 A, 208-240 VAC 05945-109-01-69
