07610-004-92-22-A
30
FRAME
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 4 Bolt, 1/4-20 x 1/2” 05305-274-02-00
2 4 Locknut, 1/4-20 Hex with Nylon Insert 05310-374-02-00
3 1 Frame 05700-031-48-01
4 4 Bullet Foot 05340-108-01-03
5 4 Flanged Bullet Foot (Optional) 05340-002-34-86
2
1
3
4
5
To Next Page
