29
07610-004-92-22-A
TUB
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Track Assembly 05700-002-01-00
2 1 Sump Strainer 05700-001-22-23
3 1 Bracket, Sump Strainer 05700-001-22-24
4 1 O-ring 05330-002-60-69
5 1 Bulk Head Plug 04730-609-05-00
6 2 Bolt, Hex 3/8-16 x 1 1/4" Long 05305-276-10-00
7 1 Lower Wash Manifold 05700-031-46-00
8 1 Gasket 05700-111-35-03
9 1 Scrap Screen 05700-003-07-76
10 1
Standpipe Lift
Standpipe Lift Support (Not Shown)
05700-002-91-54
05700-002-91-55
11 1 Standpipe 05700-001-25-69
12 1 Switch, Dual Float 06680-121-70-71
13 1 Washer, Flat, 1/2" 05311-011-71-93
14 1 Nut, 1/2-13 05310-011-72-58
15 1 Fitting, 1/4" 05310-924-02-05
16 1 Probe, Thermistor 4" 06685-004-17-26
17 1 Nut, Hex, 5/16-18 05310-275-01-00
18 1 Lockwasher, 5/16", Split 05311-275-01-00
19 1 Heater See Heaters page.
20 1 Wash Heater Gasket 05330-011-47-79
21 1 Wash Motor See Motors page.
22 1 Nipple 05700-021-34-84
23 1 Discharge Hose 05700-011-88-24
To Next Page
