PARTS
PLUMBING
ITEM QTY DESCRIPTION PART NUMBER
1 Plumbing, Complete Assembly 05700-004-54-52
1 1 Plumbing, Inlet 05700-004-47-98
2 1 Vacuum Breaker, 1/2" Brass 04820-003-06-13
3 3 Plug, Rinse Injector, 1/8” Brass 04730-209-07-37
4 1 Casting, 1/2" Flanged Coupling 05700-004-47-97
5
1
1
Rinse Injector
Gasket, Rinse Injector (Not Shown)
05700-002-56-75
05330-111-42-81
6 3 Washer, 1/4-20 Hex with Nylon Insert 05311-174-01-00
7 3 Locknut, 1/4-20 Hex with Nylon Insert 05310-374-01-00
8 1 Gasket, Rinse Manifold 05330-003-75-91
9 1 Decal, 10 PSI 09905-004-50-73
10 1 Hose, 1/2" x 31" Blue 05700-004-54-56
11 2 Elbow, 1/2" 90-degree Brass 04730-011-42-96
12 1 Hose, 1/2" x 33" Red 05700-004-51-62
13 1 Solenoid Valve, 1/2" 04810-003-71-56
