Noble HT-180EC - Page 44

39
07610-004-92-22-A
*Rinse Arm Bearing Kit
(Includes items 11 and 12)
06401-004-57-50
PARTS
WASH & RINSE ASSEMBLIES
ITEM QTY DESCRIPTION PART NUMBER
1 1 Upper Manifold 05700-031-34-82
2 4 Nut, 3/8-16 Hex 05310-276-01-00
3 4 Lockwasher, 3/8" 05311-276-01-00
4 2 Bolt, Hex 3/8-16 x 7/8" 05306-011-36-95
5 2 O-ring 05330-111-35-15
6 1 Positioning Bracket, Manifold Tube 05700-011-34-63
7 1 Tube, Wash Manifold 05700-131-15-07
8 2 Gasket, Manifold 05700-111-35-03
9 1 Wash Arm 05700-004-13-13
10 5 Locknut, 1/4-20 Hex with Nylon Insert 05310-374-01-00
11* 2 Clip, Retaining, Rinse Head Bushing 05340-112-01-11
12* 2 Bearing Assembly, Rinse Arm 05700-004-54-71
13 2 Rinse Arm 05700-003-58-94
14 4 Rinse Arm End-cap 04730-111-60-41
15 1 Lower Wash Manifold 05700-031-46-00
16 2 Bearing Assembly 05700-021-35-97
17 1 Rinse Manifold Assembly 05700-021-47-61
18 2 Bolt, Hex 3/8-16 x 1 1/4" 05305-276-10-00
19 4 Wash Arm End-cap 05700-003-31-59
