7
Table1: Main technical data for standard version
Type sheet for industrial truck acc. to VDI 2198
General data
1.2
Manufacturer`s type designation
PSE12BD
PSE12ND
1.3
Power (battery ,diesel, petrol, gas, manual)
Battery
1.4
Operator type
Pedestrian
1.5
Load Capacity / rated load
Q(t)
1.2
Load Capacity / rated load (mast lift)
1.2
3)
Load Capacity / rated load (support arm lift)
1.2
3)
1.6
Load centre distance
c(mm)
600
1.8
Load distance ,centre of drive axle to fork
x(mm)
835 / 752
4)
1.9
Wheelbase
Y(mm)
1264 / 1181
4)
Weight
2.1
Service weight
kg
700
670
2.2
Axle loading, laden front/rear
kg
505 / 195
485 / 185
2.3
Axle loading, unladen front/rear
kg
680 / 1220
670 / 1200
Tires, chassis
3.1
Tires
Polyurethane (PU)
3.2
Tire size, front
 x w (mm)
Φ210 x 70
3.3
Tire size, rear
 x w (mm)
Φ84 x 93
3.4
Additional wheels(dimensions)
 x w (mm)
Φ100 x 50
3.5
Wheels, number front/rear(x=driven
wheels)
1x + 1 / 2
3.6
Track, front
b
10
(mm)
550
3.7
Track, rear
b
11
(mm)
400 / 515
Dimensions
4.2
Lowered mast height
h
1
(mm)
2320
4.3
Free Lift height
h
2
(mm)
-
4.4
Lift height
h
3
(mm)
3514
4.5
Extended mast height
h
4
(mm)
4077
4.6
Initial lift
h
5
(mm)
120
4.9
Height of tiller in drive position min./ max.
h
14
(mm)
710 / 1150
4.15
Height, lowered
h
13
(mm)
86
4.19
Overall length
l
1
(mm)
1752
4.20
Length to face of forks
l
2
(mm)
602
4.21
Overall width
b
1
(mm)
800
4.22
Fork dimensions
s/e/l (mm)
60 / 180 / 1150
4.25
Width across forks
b
5
(mm)
570 / 685
4.32
Ground clearance, centre of wheelbase
m
2
(mm)
26
4.33
Aisle width for pallets 1000X1200
crossways
Ast (mm)
2290 / 2234
4)
4.34
Aisle width for pallets 800X1200
lengthways
Ast (mm)
2209 / 2185
4)
4.35
Turning radius
Wa (mm)
1467 / 1384
4)
Performance
5.1
Travel speed, laden/ unladen
Km/h
4.2 / 4.5
5.2
Lift speed, laden/ unladen
m/s
0.11 / 0.16
5.3
Lowering speed, laden/ unladen
m/s
0.13 / 0.11
