Nokia 101 Service Manual

Nokia 101 (RM-769)
Nokia 100 (RH-130/RH-131)
L1L2 Service Manual
3
Co nf id e nt ial | Co p yrig ht © 2011 Nokia | A ll rights reserved
V e rsion 1 .0
CHANGE HISTORY
Status
Version No.
Date
Comments
Approved
1.0
30.08.2011
First approved version
The purpose of this document is to help NOKIA service levels 1 and 2 workshop technicians to
carry out service to NOKIA products. This Service Manual is to be used only by authorized NOKIA
service suppliers, and the content of it is confidential. Please note that NOKIA provides also other
guidance documents (e.g. Service Bulletins) for service suppliers, follow these regularly and
comply with the given instructions.
While every endeavor has been made to ensure the accuracy of this document, some errors may
exist. If you find any errors or if you have further suggestions, please notify NOKIA using the
address below:
Nokia Care Academy
service.manuals@nokia.com
Please keep in mind also that this documentation is continuously being updated and modified,
so watch always out for the newest version.

Nokia 101 Specifications

General

Display type	TFT
Display diagonal	1.8 \
Display resolution	128 x 160 pixels
Display number of colors	65536 colors
Internal memory	- MB
Flash card support	Yes
Maximum memory card size	16 GB
Rear camera resolution (numeric)	0 MP
Headphone connectivity	3.5 mm
Data network	GSM
SIM card capability	Dual SIM
2G bands (primary SIM)	900, 1800 MHz
2G bands (secondary SIM)	900, 1900 MHz
Multimedia Messaging Service (MMS)	-
Ringer type	Polyphonic
Audio formats supported	MP3
Polyphonic rings quantity	32
Form factor	Bar
Personalization	Icons, Menu, Themes
Phonebook capacity	500 entries
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes
Operating system installed	-, 30
Product color	Black
Battery type	BL-5CB
Talk time (2G)	6.7 h
Battery capacity	800 mAh
Standby time (2G)	600 h
Continuous audio playback time	26 h
Subscription type	No subscription

Weight and Dimensions

Depth	14.9 mm
Width	45.5 mm
Height	110 mm
Volume	73 cm³
Weight	71 g
