Name Ball No. Test point Function
VRF1 H10 C7121 1.8V DCDC output voltage, supply of
1.3V LDOs
VDDTRX B14 C7124 1.4V Transceiver supply
VDDTDC B12 C7131 1.3V VDD for Time to Digital
Converter of DPLL
VDDMS H13 C7123 1.3V Mixed signal supply
VDDXO E11 C7130 1.3V DCXO supply
VDDMMD A12 NONE 1.3V VDD for Multi Modulus Divider of
DPLL
RM-761; RM-799; RM-800
RF Troubleshooting
Issue 1 COMPANY CONFIDENTIAL Page 4 – 17
Copyright © 2011 Nokia. All rights reserved.

Nokia 2000 Specifications

General

Announced	2000
SIM	Mini-SIM
Display Type	Monochrome graphic
Phonebook	Yes
Loudspeaker	No
3.5mm jack	No
Messaging	SMS
Radio	No
Internal memory	No
Network	GSM
Alert types	Vibration; Monophonic ringtones
