Nokia 3000 User Manual

PCS-1 Power cable
The PCS-1 power cable (DC) is used with a docking station, a module
jig or a control unit to supply a controlled voltage.
XRS-6 RF cable
The RF cable is used to connect, for example, a module repair jig to
the RF measurement equipment.
SMA to N-Connector approximately 610 mm.
Attenuation for:
•
GSM850/900: 0.3+-0.1 dB
•
GSM1800/1900: 0.5+-0.1 dB
•
WCDMA: 0.6+-0.1dB
Service concepts
Note:
For service concepts please refer to SR993.
RM-781
Service Devices and Service Concepts
Page 2 – 12 COMPANY CONFIDENTIAL Issue 1
Copyright © 2011 Nokia. All rights reserved.

Nokia 3000 Specifications

General

Network	GSM
SIM	Mini-SIM
Phonebook	Yes
Call records	Yes
WLAN	No
2G bands	GSM 900 / 1800
Alert types	Vibration
Messaging	SMS
Games	Yes
Battery	Removable battery
Colors	Black, White, Pink, Blue, Green
Status	Cancelled
