Nokia 3100 - Page 76

Nokia 3100 and Nokia 3120 User Guide 71 Copyright © 2004 Nokia
Technical information (3100 and 3120)
Technical information
(3100b and 3120b)
Feature Specification
Dimensions Width 1.68 in (42.8 mm)
Height 4.00 in (1.08 mm)
Depth 0.76 in (19.6 mm)
Weight 87.4 gm
with BL-5C Li-Ion Battery
Wireless networks GSM 850, 1800, and 1900 networks
Size (volume) 4.09 cu in (67 cu cm)
Frequency range (Tx) GSM 850: 824–849 MHz
GSM 1800: 1710–1785 MHz
GSM 1900: 1850–1910 MHz
Frequency range (Rx) GSM 850: 869–894 MHz
GSM 1800: 1805–1880 MHz
GSM 1900: 1930–1990 MHz
Tx output power 2W (GSM 850 max)
1W (GSM 1800/GSM 1900 max)
Battery voltage 3.7 Vdc
Number of channels GSM 850: 124
GSM 1800: 374
GSM 1900: 299
