Nokia 3210 Service & Repair Manual

CONFIDENTIAL
Service & Analysis Center Europe
Training Team
version 1.0 / 05.11.1999 Page 12 of 37
C111, C115, C113 faulty
• Check the current consumption in different operation modes (refer to the table below)
• Check if the high current consumption comes from the VB, Vout or output voltages of CCONT
• Disconnect coil by coil L105 (→N702) L505, L506 (→PA's) and check consumption again
• Check and disolder C111, C115 and C113
• calibrate Battery value if charging stops to early or battery is to hot after charging (see also chapter "Not
charging)
Figure 1: current consumption values
Function mode Minimum current in mA Maximum current in mA
Off state 0 1
Sleep mode 2 8
Call mode GSM 900 0 1000
Call mode GSM 1800 0 1000

Nokia 3210 Specifications

General

Release Year	1999
Dimensions	123.8 x 50.5 x 16.7 mm (4.87 x 1.99 x 0.66 in)
Display Type	Monochrome graphic
Display Size	5 lines
Stand-by Time	Up to 260 h
Talk Time	Up to 4 h 30 min
Network Technology	GSM
2G bands	GSM 900 / 1800
Announced	1999
Status	Discontinued
SIM	Mini-SIM
Resolution	84 x 48 pixels
Memory Card slot	No
Call records	10 dialed, 10 received, 10 missed calls
Alert types	Vibration; Monophonic ringtones
Loudspeaker	No
3.5mm jack	No
Messaging	SMS
Radio	No
Clock	Yes
Alarm	Yes
Java	No
Battery Type	Removable Li-Ion 1250 mAh battery
Games	Memory, Snake
Weight	151 g
