Nokia 3210 Service & Repair Manual

CONFIDENTIAL
Service & Analysis Center Europe
Training Team
version 1.0 / 05.11.1999 Page 4 of 37
Doesn't Switch on
Check VB (Battery 2,4V-3V)
on L102
check connector X101/ X102
change if bend or soiled
Phone doesn't switch on, section: DC / DC converter
check the connection between
L102 and R132 (0 Ohm)
Swap the phone if the
connection is open
check solder of V105 or
change if necessary
check the voltage on V101
anode 2,6V; cathode 3,2V
check solder of V105 or
change if necessary
check also R102, R105, R112
DC/ DCconverter is oK!
continue with CCONT
Check 600KHz switching
frequency on Pin 4,5,12,13 of
V105
Check 1,2V operation voltage
on Pin 15 of V105
No
No
No
No
No
Yes
Yes
Yes
check the solderings and
resistance of L102 "0Ohm"
resolder or change L102
check pin 3 from V105
on="low"status 0Ohm
Yes
No
Yes
Yes
check V109 and the
respective voltage deviders
R131,132,134,143,144
No

Nokia 3210 Specifications

General

Release Year	1999
Dimensions	123.8 x 50.5 x 16.7 mm (4.87 x 1.99 x 0.66 in)
Display Type	Monochrome graphic
Display Size	5 lines
Stand-by Time	Up to 260 h
Talk Time	Up to 4 h 30 min
Network Technology	GSM
2G bands	GSM 900 / 1800
Announced	1999
Status	Discontinued
SIM	Mini-SIM
Resolution	84 x 48 pixels
Memory Card slot	No
Call records	10 dialed, 10 received, 10 missed calls
Alert types	Vibration; Monophonic ringtones
Loudspeaker	No
3.5mm jack	No
Messaging	SMS
Radio	No
Clock	Yes
Alarm	Yes
Java	No
Battery Type	Removable Li-Ion 1250 mAh battery
Games	Memory, Snake
Weight	151 g
