Nokia 3210 Service & Repair Manual

CONFIDENTIAL
Service & Analysis Center Europe
Training Team
version 1.0 / 05.11.1999 Page 15 of 37
Contact service COBBA parallel /serial bus fail
COBBA parallel/
serial bus failed
Contact Service
Check via WINTESLA / Testing / Selftest
which kind of selftest is fail
check COBBACLK
13MHZ/ 3,2Vpp on
J201
check soldering or
change N100, C117
check VBB 2,8V on
C117
Check VCOBBA 2,8V
DC on C148
Change or check
soldering of N100,
C148
Check 13MHz RFC
on C301
swap the phone
because MAD or PCB
should be the reason
Change the COBBA
Check COBBA reset
pulse during
initialisation routine
on J343 (see diagram)
swap the phone
because MAD or PCB
should be the reason
check soldering or
change G701, V702
Yes
not oK
oK
not oK
oK
not oK
oK
not oK
oK
oK
not oK

Nokia 3210 Specifications

General

Release Year	1999
Dimensions	123.8 x 50.5 x 16.7 mm (4.87 x 1.99 x 0.66 in)
Display Type	Monochrome graphic
Display Size	5 lines
Stand-by Time	Up to 260 h
Talk Time	Up to 4 h 30 min
Network Technology	GSM
2G bands	GSM 900 / 1800
Announced	1999
Status	Discontinued
SIM	Mini-SIM
Resolution	84 x 48 pixels
Memory Card slot	No
Call records	10 dialed, 10 received, 10 missed calls
Alert types	Vibration; Monophonic ringtones
Loudspeaker	No
3.5mm jack	No
Messaging	SMS
Radio	No
Clock	Yes
Alarm	Yes
Java	No
Battery Type	Removable Li-Ion 1250 mAh battery
Games	Memory, Snake
Weight	151 g
