Nokia 3210 Service & Repair Manual

CONFIDENTIAL
Service & Analysis Center Europe
Training Team
version 1.0 / 05.11.1999 Page 17 of 37
Contact Service-CCONT interface fail
Check soldering or change
R413, S416
Check if PWRON 3,2V
drops to 0V on R413 during
pressing the power button
Check the 32.768KHz
square wave on C149
Check if PURX goes up to
2,8V DC on R303
Check if VCXOPWR goes
up to 2,8V DCon J340
Check if VXO goes up to
2,8V DC on C102
change CCONT
Change CCONT
Check if VBB goes
up to 2,8V DC on C117
Check if VREF goes up to
1,5V DC on C123
Contact Service
Check via WINTESLA / Testing / Selftest
which kind of selftest is fail
CCONT interface failed
Change or check soldering
of B100, C147, C148, C153,
N100
swap the phone because
MAD or PCB should be the
reason
Change or check soldering
of G701, V702...
Check if RFC 13MHz at
C301 (2,8Vpp)
change CCONT
change CCONT
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
No
No
No
No
No
No

Nokia 3210 Specifications

General

Release Year	1999
Dimensions	123.8 x 50.5 x 16.7 mm (4.87 x 1.99 x 0.66 in)
Display Type	Monochrome graphic
Display Size	5 lines
Stand-by Time	Up to 260 h
Talk Time	Up to 4 h 30 min
Network Technology	GSM
2G bands	GSM 900 / 1800
Announced	1999
Status	Discontinued
SIM	Mini-SIM
Resolution	84 x 48 pixels
Memory Card slot	No
Call records	10 dialed, 10 received, 10 missed calls
Alert types	Vibration; Monophonic ringtones
Loudspeaker	No
3.5mm jack	No
Messaging	SMS
Radio	No
Clock	Yes
Alarm	Yes
Java	No
Battery Type	Removable Li-Ion 1250 mAh battery
Games	Memory, Snake
Weight	151 g
