Nokia 3210 Service & Repair Manual

CONFIDENTIAL
Service & Analysis Center Europe
Training Team
version 1.0 / 05.11.1999 Page 27 of 37
• If message "SIM Card not accepted" appears on LCD after entering PIN code,
a SIM LOCK is probably activated in this phone
• Or COBBA has been changed and not reprogrammed with the SIM-LOC DATA
• Initialise phone into normal mode and activate Quick/ RF-info (WINTESLA)
compare the SIM LOCK entries with the references from the operator. Look at Figure: List of current SIM-LOC…
N100, CCONT
• Refer to insert SIM Card procedure
N200, COBBA
• Change COBBA if all SIM LOCK entries and SIM-CARD signals
from CCONT are OK
Note! Rewrite SIMLOCK and IMEI entries with use of the Nokia security SW (SSSW) and make a SW-update or send
this phones to the SACE, if this procedure is not permitted to you

Nokia 3210 Specifications

General

Release Year	1999
Dimensions	123.8 x 50.5 x 16.7 mm (4.87 x 1.99 x 0.66 in)
Display Type	Monochrome graphic
Display Size	5 lines
Stand-by Time	Up to 260 h
Talk Time	Up to 4 h 30 min
Network Technology	GSM
2G bands	GSM 900 / 1800
Announced	1999
Status	Discontinued
SIM	Mini-SIM
Resolution	84 x 48 pixels
Memory Card slot	No
Call records	10 dialed, 10 received, 10 missed calls
Alert types	Vibration; Monophonic ringtones
Loudspeaker	No
3.5mm jack	No
Messaging	SMS
Radio	No
Clock	Yes
Alarm	Yes
Java	No
Battery Type	Removable Li-Ion 1250 mAh battery
Games	Memory, Snake
Weight	151 g
