PAGE 9 (23) Approved 4.0
CMO Operations & Logistics
MGR
WW Service Solutions & Development
Bochum / Germany CONFIDENTIAL 14.7.2005
7. SERVICE TOOLS
FLS-4S incl. ACF-8, Driver and User Guide
Dongle and flash device incorporated into one package,
developed specifically for POS use.
ACF-8
Universal Power Supply is used to power FLS-4S.
Internal Battery BL-5B
Inserted under the back cover, this Li-Ion 760 mAh battery
provides power in a lightweight package.
Travel Charger ACP-12
Small and lightweight charger for fast charging of your phone
battery.
Headset HDS-3
Small and lightweight stereo headset for handsfree functionality
and listening to FM radio.
SRT-10
Camera removal tool. One side is for disassembly, the other side
for assembly
XCS-1
Service Cable is used to connect FLS-4S to SF-6 .
Service Manual 5140/5140i Level 1&2 Copyright © 2004-2005 NOKIA Corporation. All rights reserved.
