13. Lever out the DC JACK with the DC Plug.
14. Lift up the ENGINE MODULE, but bear in mind that the ex
connector is still connected.
15. Carefully lever open the Flex connector.
16. Remove the NUMERIC KEYMAT.
17. The disassembly procedure is now completed.
