Service Manual 5200 RM-174/RM-181 / 5300 RM-146/RM-147
Copyright © 2006-2007 NOKIA Corporation. All rights reserved.
Approved 4.0
MGR
Page (46)
11.2 A-Cover Assembly
11.3 1TG UI Module Assembly
11.4 1TG UI Module Assembly
11.5 Slide Flex
11.6 Connector (X2402)
QUICK TROUBLE SHOOTER - SIDEKEYS 23.
