Nokia 5610 User Manual

12
CONFIDENTIAL
Copyright © 2007-2008 NOKIA. All rights reserved.
5610 Xpress Music RM-242/RM-279/RM-358/RM-359
Page
(24) ISSUE 2
Service Manual Level 1&2
17. Unlock these 3 plastic clips with the SS-93. 18. Turn the assembly. Gently lift up the BOTTOM KEYMAT
SUPPORT.
19. The BOTTOM DOMESHEET was glued in at the SLIDE MODULE
ASSEMBLY. Gently release the domesheet on both sides.
20. Now the BOTTOM DOMESHEET can be removed. Remove any
adhesive residues from the opponent part.
21. Keep this adhesive clean if this part should be used again. 22. Carefully release the LOWER BEZEL ASSEMBLY from the metal
snaps of the SLIDE MODULE ASSEMBLY.
23. Shift the LOWER BEZEL ASSEMBLY into direction of the
threads. It can be lifted up now.
24. Prevent mechanical stress to the NAVI SLIDER MODULE while
unscrewing the screws.

Nokia 5610 Specifications

General

Display type	LCD
Display diagonal	2.2 \
Display resolution	240 x 320 pixels
Display number of colors	16.78 million colors
Internal memory	20 MB
Flash card support	Yes
Rear camera resolution (numeric)	3.2 MP
Interface	Series 40
Networking type	GSM/WCDMA
Playback formats	MP3, MP4, AAC, eAAc+, WMA
Browser supported	Opera mini, XHTML
Operating frequency	850/900/1800/1900/2100 MHz
USB 2.0 ports quantity	1
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Ringer type	Polyphonic
Battery type	BP-5M
Talk time (2G)	6 h
Battery capacity	900 mAh
Standby time (2G)	320 h
Form factor	Slider
Embedded games	4
Phonebook capacity	2000 entries
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Countdown timer, Notes, Stopwatch, To-do list
Bluetooth version	2.0+EDR
Specific absorption rate (SAR) value (EU)	1.14 . W/kg
Data network	GPRS, HSCSD

Weight and Dimensions

Depth	17 mm
Width	48.5 mm
Height	98.5 mm
Weight	111 g
