Type Description
GPIB control cable
USB cable
Service concept for RF testing and RF/BB tuning
Figure 7 Service concept for RF testing and RF/BB tuning
Type Description
Product specific devices
MJ-135 Module jig
Other devices
CU-4 Control unit
PKD-1/PK-1 SW security device
SX-4 Smart card
Measurement equipment
Smart card reader
PC with Phoenix service software
Cables
DAU-9s MBUS cable
RM-243
Service Tools and Service Concepts
Page 2 –20 COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.
