7. Check the correct positioning of the keys before continuing.
8. Now insert the VOLUME KEY and on the opposite side the
FUNCTION/POWER KEY. Take special care not to bend the spring
contacts.
9. Place the ENGINE BOARD into the D-COVER.
10. Insert the board screw with tweezers.
11. Set the correct torque and tighten in.
12. Place the Push to Open Button into the HINGE CAP RIGHT.
