Service Manual 6131/6133 RM-115 - - 6126/H/6133/b/h RM-126
Copyright © 2006 NOKIA Corporation. All rights reserved.
Approved 1.0
MGR
Page
(29)
1. Insert the BATTERY SPRING and click it into its place.
2. Insert the ANTENNA MODULE into its compartment.
3. Place the BLUETOOTH ANTENNA.
4. Carefully insert the MICROPHONE into its compartment.
5. Use the DC Plug to reassemble the DC JACK.
6. Insert the Buttons and lock them with your ngers.
LOWER BLOCK ASSEMBLY11.
