Nokia 6131 Service Manual

WW Competence Transfer
CMO Operations & Logistics
Multimedia Creation & Support CONFIDENTIAL
6.Apr.2006
8
Service Manual 6131/6133 RM-115 - - 6126/H/6133/b/h RM-126
Copyright © 2006 NOKIA Corporation. All rights reserved.
Approved 1.0
MGR
Page (29)
FLS-4S incl. ACF-8, Driver and User Guide
Dongle and flash device incorporated into one package, devel-
oped specifically for POS use.
ACF-8
Universal Power Supply is used to power FLS-4S.
Travel Charger AC-4
Small and lightweight charger for fast charging of your phone
battery.
Internal Battery BL-4c
Inserted under the back cover, this Li-Ion battery provides
power in a lightweight package.
Headset HS-23
Small and lightweight stereo headset with handsfree call han-
dling, volume control, push to talk support, and comfortable
earpieces for listening to the FM radio or music player.
RJ-92
Soldering Jig
CA-53
Service Cable to connect the PC with the Pop-Port™ connector.
SERVICE TOOLS6.

Nokia 6131 Specifications

General

Display Type	TFT, 16M colors
Display Size	2.2 inches
Resolution	240 x 320 pixels
Main Camera	1.3 MP
Selfie Camera	No
Dimensions	92 x 48 x 20 mm
Weight	112 g
Internal Storage	11 MB
Card Slot	microSD (dedicated slot)
Network Technology	GSM
2G bands	GSM 850 / 900 / 1800 / 1900
GPRS	Class 10
EDGE	Class 10
Announced	2006, February
Status	Discontinued
SIM	Mini-SIM
Video	Yes
Alert types	Vibration; Downloadable polyphonic, MP3 ringtones
Loudspeaker	Yes
3.5mm jack	No
WLAN	No
Radio	FM radio
USB	Pop-Port
Messaging	SMS, MMS, Email, Instant Messaging
Browser	WAP 2.0/xHTML
Games	Yes + Downloadable
Java	Yes, MIDP 2.0
Stand-by	Up to 240 h
Infrared port	Yes
Battery	Removable Li-Ion 820 mAh battery (BL-4C)
Platform	Series 40
Bluetooth	2.0, A2DP
Colors	Black, Red
