Nokia 6310 Manual

CONFIDENTIAL
5 (29)
NPE-4 6310/NPL-1 6310i Repair Hints
Customer Care Europe, Middle East & Africa Version 3.0 Approved
SCCE Training Group Date 22.04.2003
© NMP 2003
Checked by:
SCCE Training Group
Approved by:
SCCE
Contents
PREFACE
GENERAL 2
CHAPTER 1
Additional information 6
- BB shield removing instructions 6
- Different battery connectors 7
- Auto power off 7
NPE-4 (6310) & NPL-1 (6310i) 8
CHAPTER 2
CarKit problems 8
- “Phone not connected” or “Phone error” 8
- Problems Solved by the MCU SW 5.50(only NPL1) 8
CHAPTER 3
Totally dead/ “Does not switch on” 9
- Check current consumption 9
- Flash the phone 9
- Voltages and signals to check 10
NPE-4 6310 12
CHAPTER 4
Electrical faults 12
- Drop calls 12
- No service, memory problem 13
- No service, no RSSI 13
- RX flowchart 15
- No service, no TX 16
- TX flowchart 18
- Display too dark/ too light 19
CHAPTER 5
Hookswitch problems 20
- Sometimes not possible to release “incoming call” 20
- No voice dial possible 20

Nokia 6310 Specifications

General

Form factor	Bar
Personal info management (PIM)	-
Subscription type	No subscription
Type	Entry-level phone
Color name	Dark Green
Product color	Green
Display diagonal	2.8 \
Display resolution	320 x 240 pixels
Rear camera	Yes
Rear camera resolution (numeric)	0.3 MP
Data network	GPRS, GSM
SIM card capability	Dual SIM
2G bands (primary SIM)	900, 1800 MHz
Mobile network generation	2G
Talk time (2G)	19.45 h
Battery capacity	1150 mAh
Standby time (2G)	520.8 h
USB version	2.0
USB connector type	Micro-USB
Headphone connectivity	3.5 mm
Bluetooth version	5.0
Bluetooth profiles	A2DP
RAM capacity	16 MB
ROM capacity	8 MB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB

Weight and Dimensions

Depth	14.1 mm
Width	56 mm
Height	135.5 mm
Weight	- g
