5. GENERAL REPAIR INFORMATION
In this section you will get some general hints how to carry out repairs:
o
Before starting the repair you must take care of ESD precautions like being in your
ESD-area and connecting your wristband.
o
Use gloves to avoid corrosion and fingerprints.
o
Protect windows and displays with a foil to avoid dust and scratches.
o
When cleaning the pads you have to use a soft cloth and isopropanol. It is not
allowed to use a glass fiber pencil because it scratches the surface and will lead
later on to corrosion.
o
Soldering with
manual hot air gun
is totally forbidden because of the very
sensitive µBGA components and µVia technology. Please check general Service
Bulletin-122.
o
Mechanical parts, which didn’t repair the failure, can be reused, if they are not
soldered.
o
Use always original Nokia parts or accessories.
o
Meet the torque requirements when assembling the unit (see also the document
“torques for transceiver assembly” on Partner Websites).
o
Always use your own equipment for testing where you are sure that it works. E.g.
if the customer complains about charger function, please test the phone with your
own charger to be sure if phone or charger causes the malfunction.
o
The bottom side of a module is the side where the part no. of the pcb is seen.
o
Please check Partner Websites (PWS) for latest news and files on a regular
basis.
Legend for Quick Trouble Shooter:
This legend is valid for all parts of the
Quick Trouble Shooter
Follow the steps until the problem is solved. If this doesn’t help, you are not authorized
to go forward. Only underlined components ( e.g
. I007
) can be changed.
Follow the arrows step by step
Pads or contacts: Check optical and mechanical condition as well as corrosion.
Clean if necessary.
Measure component for electrical functionality and change, if needed.
No more action possible, send product to the
appropriate service partner with higher service level.
End Point
4, 5
Superscript numbers are for additional comments or instructions
