Nokia 7310 Supernova Service Manual

13
CONFIDENTIAL
Copyright © 2008 NOKIA. All rights reserved.
7310 Supernova RM-378/RM-379
Page (14)
ISSUE 1
Service Manual Level 1&2
17. Unlock the PWB with the SRT-6. 18. Remove the UI Assy.
19. Carefully open the LCD connector. 20. Use the SS-88 to remove the Camera Module.
21. Remove the Earpiece and discard it. 22. Ensure that no adhesive remains.

Nokia 7310 Supernova Specifications

General

Brand	Nokia
Model	7310 Supernova
Category	Cell Phone
Language	English
