3 Keypad
4 Earpiece
5 Wrist strap hole
6 Volume up/Zoom key
7 Volume down/Zoom key
8 Key lock switch
9 End/Power key
10 Microphone
11 Nokia AV Connector (3.5 mm)
12 Micro USB connector
13 Charger connector
14 Camera lens
15 Loudspeaker
Insert a SIM card and battery
Note: Switch the device off and disconnect the
charger and any other device before removing any covers.
Avoid touching electronic components while changing any
covers. Always store and use the device with any covers
attached.
8Get started
8 www.nokia.com/support
