31. To detach the ANTENNA MODULE ASSEMBLY,
carefully bend the CHASSIS as shown. Push the
ANTENNA MODULE ASSEMBLY up from the other side.
32. Remove the ANTENNA MOD ULE ASSEMBLY.
33. Lever up the DC JACK with the DC plug as shown.
34. Remove the DC JACK.
35. Lever up the AV JACK with the AV plug as shown. 36. Remove the AV JACK.
