Nokia DNT2Mi sp/mp - 4.2.1 Terminal interfaces

Data Network Terminal Single-port and Multiport Operating Instructions
20 (128) © Nokia Corporation DN01145897
Nokia Proprietary and Confidential Issue2-0en
Figure 8. Line interface connector
4.2.1 Terminal interfaces
This section briefly introduces the DTE interface unit options. For more detailed
information, refer to document DTE Interface Units for Nokia Data Network
Terminals Operating Instructions.
123456
6-pin modular jack, RJ-11
Line
1.
2.
3. Not connected
4. Not connected
5.
6.
Pin
Line 1a
Line interface
Line 1b
Line 2a (not in use in 2-w mode)
Line 2b (not in use in 2-w mode)
