Nokia DNT2Mi sp/mp - Page 78

Data Network Terminal Single-port and Multiport Operating Instructions
78 (128) © Nokia Corporation DN01145897
Nokia Proprietary and Confidential Issue2-0en
Figure 55. Main Q1 menu structure
1 Fault display
2 Local alarm cancel *)
3 Reset local cancel *)
4 Identifications
5 Controls
6 Settings
7 Measurements
8 Statistics
9 Testing *)
10 User privileges
11 Miscellaneous *)
DNT2Mi (B)
Line:
Test mode
Port1:
Far and alarm
1
DNT Identifications:
0 Display
2 Eq name
DNT controls:
0 Display
1 All test loops off
2 Port test loops
3 Line test loops
4
5
DNT settings:
0 Display
1 Service options
2 Timing source
3 Line settings
4 Port settings
5 Timeslot use
6 Default settings
7 Load factory settings
6
DNT measurements:
0 Display all
7
DNT statistics:
8
DNT privileges:
1 Password
4 Setting parameters
5 Front panel rights
10
*) not implemented
1 Eq type
5 HW units
6 SW version
7 Modify
4 Self test
1 Noise margins
4 Attenuations
5 Line voltage
2 Rx levels
3 Tx levels
4 System counters
99 Reset all statistics
1 Port statistics
2 Line1 statistics
3 Line2 statistics
