Using Q1 menus
DN01145897 © Nokia Corporation 81 (128)
Issue 2-0 en Nokia Proprietary and Confidential
Figure 58. Controls menu
Port test loops:
Give port number
1,2 or 3
5
5,2
5,2, port #
5,4
DNT controls:
0 Display
1 All test loops off
2 Port test loops
3 Line test loops
4 Self test
Port port# test loops:
0 Display
1 Port test loops off
2 Loop to line (DL)
3 Loop to DTE (LL)
4 Tx-Rx test (TR)
5,3
Self test:
0 Result of last ST
1 Start Self Test
Line test loops:
0 Display
1 Line test loops off
2 Loop to Line (DL)
