Figure 61. Settings menu structure (continued)
Line settings:
0 Display
3 Line interface
6 Power backoff
8 BER alarm limit
9 BER alarm severity
6,3
Line interface
SHDSL mode:
1 STU-C (fixed)
2 STU-R (rate adaptive)
6,3,3
6,4
6,5
6,6
6,7
6,3,3,1
Line if: STU-C
2/4-wire mode:
2 Two-wire
4 Four-wire
6,3,3,1,2
Line if: STU-C, 2w, PSDS
Give line rate
n = 3 .. 32
6,3,3,1,4
Line if: STU-C, 4w, PSDS
Give line rate
n = 6 .. 32 (even number)
6,3,6
6,3,8
6,3,9
psdS = Power special density mask, Symmetric
32 = Line rate, the value of n x 64k
For more information, refer to Section 9.3.4 "Line settings"
6,3,3,2
Line if: STU-R
2/4 wire mode:
2 Two-wire
4 Four-wire
