• Connection name — Enter a descriptive name
for the connection.
• Data bearer — Select Wireless LAN.
• WLAN network name — To enter the service
set identifier (SSID), that is, the name that
identifies the specific WLAN, select Enter
manually. To select the network from the
WLANs in range, select Search for networks.
• Network status — Select Hidden if the
network you are connecting to is hidden or
Public if it is not hidden.
• WLAN network mode — If you select
Infrastructure, devices can communicate with
each other and with wired LAN devices through
a WLAN access point. If you select Ad-hoc,
devices can send and receive data directly with
each other, and no WLAN access point is needed.
• WLAN security mode — You must select the
same security mode that is used in the WLAN
access point. If you select WEP (wired equivalent
privacy), 802.1x, or WPA/WPA2 (Wi-Fi protected
access), you must also configure the relevant
additional settings.
• WLAN security settings — Edit the security
settings for the selected security mode.
• Homepage — Enter the web address of the
page you want to display as the home page
when you use this access point.
To set up a WLAN access point automatically, use the
WLAN wizard. Select Menu > Connectivity > WLAN
wiz..
Advanced access point
settings for WLAN
Select Menu > Tools > Settings > Connection >
Access points.
After setting up a basic access point for WLAN, select
Options > Advanced settings, and define the
following advanced settings:
• IPv4 settings — Enter the device IP and name
server addresses for the IPv4 internet protocol.
• IPv6 settings — Select or enter the name server
addresses for the IPv6 internet protocol.
• Ad-hoc channel — The channel is usually chosen
automatically. To enter the channel number (1-11)
manually, select User defined.
• Proxy server address — Enter the proxy server
address.
• Proxy port number — Enter the proxy server port
number.
Connect PC to web
You can use your device to connect your PC to the web.
1. Connect the data cable to the USB connectors of
your device and your PC.
2. Select Connect PC to web. The necessary software
is automatically installed from your device to the
PC.
3. Accept the installation in your PC. If asked, accept
also the connection. When the connection to the
71
