Item Side Grid Description and value
R7002 Bottom T 8 0402R CHIPRES JUMPER 0R0 0402
R7501 Bottom R 4 0402R CHIPRES 0W06 2K2 J 0402
R7502 Bottom S 5 0402R CHIPRES 0W06 10K F 0402
R7503 Bottom Q 5 0402R CHIPRES 0W06 4K7 J 0402
R7505 Bottom R 4 0402R CHIPRES 0W06 8K2 F 0402
R7506 Bottom R 5 0402R CHIPRES 0W06 10R J 0402
R7507 Bottom S 5 0402R CHIPRES 0W06 10R J 0402
R7508 Bottom R 4 0402R CHIPRES 0W06 10R J 0402
R7509 Bottom Q 4 0402R CHIPRES 0W06 22K J 0402
R7510 Bottom Q 8 0402R CHIPRES 0W06 15R J 0402
R7522 Bottom Q 8 0402R CHIPRES 0W06 27K J 0402
R7523 Bottom S 8 0402R CHIPRES JUMPER 0R0 0402
R7560 Bottom Q 6 0402R CHIPRES 0W06 100R J 0402
S2401 Bottom O 1 SWITCH_EVQP7A01K
SM SW TACT SPST 12V SIDE KEY
2.2N
S2402 Bottom S 1 SWITCH_EVQP7A01K
SM SW TACT SPST 12V SIDE KEY
2.2N
S2403 Top U 5 SWITCH_EVQP7A01K
SM SW TACT SPST 12V SIDE KEY
2.2N
T7501 Bottom R 3 TRANS_HHM1517A2
TRANSF BALUN 3800 +/- 550MHZ
0805
T7520 Bottom S 9 TRANS_LDB15
TRANSF BALUN 1800+-100MHZ
2X1.25
V2000 Top A 4 BGA_4 ASIP TVS BGA4
V2401 Bottom H 4 SOT_666
TRX2 BIPOLAR 2XPNP 40V 0A1
0W12 SOT666
V2402 Bottom G 5 SOT_666 TRX2+RX4 N 4K7/47K SOT666
V2405 Top G 4 LED_48_21SYGC LED WHITE 140MCD 5MA 0603
V2406 Top G 6 LED_48_21SYGC LED WHITE 140MCD 5MA 0603
V2407 Top C 6 LED_48_21SYGC LED WHITE 140MCD 5MA 0603
V2409 Top C 4 LED_48_21SYGC LED WHITE 140MCD 5MA 0603
V2410 Bottom H 4 SC79
SCH DI 1PS79SB31 200MA 30V
SOD523
V2411 Bottom H 4 SOT_666
TRX2 BIPOLAR 2XPNP 40V 0A1
0W12 SOT666
V2412 Bottom M 1 LED_CL_194WH_D_BIG
LED TOP BLUE 5MA min30mcd
0603 max0.4mm
