Nokia RM-217 - RF Testing Concept with RF Coupler

Type Description
XRS-6 RF cable
USB cable
GPIB control cable
RF testing concept with RF coupler
Figure 31 RF testing concept with RF coupler
Type Description
Product specific tools
FS-47 Flash adapter
SA-123 RF coupler
Other tools
CU-4 Control unit
SX-4 Smart card
FPS-10 Flash prommer box
PKD-1/PK-1 SW security device
SS-62 Flash adapter base
Measurement equipment
PC with Phoenix service software
RM-217; RM-222
