General devices
The table below gives a short overview of service devices that can be used for testing, error analysis, and
repair of product RM-598; RM-604. For the correct use of the service devices, and the best effort of workbench
setup, please refer to various concepts.
AC-35 Power supply
Universal power supply for FPS-21; included in the FPS-21 sales
package.
Input 100V…230V 50Hz…60Hz, output voltage of 12 V and output
current up to 3 A.
RM-598; RM-604
Service Devices and Service Concepts
Page 2 –6 COMPANY CONFIDENTIAL Issue 1
Copyright © 2009 Nokia. All rights reserved.
