Nokia X3-02 - Telephone

Nokia X3-
02
RM-639
Service Manual Level 1&2
18 Confidential | Copyright © 2011 Nokia | All rights reserved Version 3.0
37) Protect the LCD with a protective film.
38) Remove the TOUCH MODULE adhesive remains
with the SS-93.
39) Remove the EARPIECE MESH with the tweezers.
Do not use it again. Discard it.
40) Push carefully the SS-93 through the opening to
release the LCD.
41) Pull the LCD connector through the opening and
remove the LCD. Do not use it again. Discard it.
42) Use the SS-93 to release the UI-FLEX ASSY.
