Nokia X3-02 - Assembly Instructions

Nokia X3-
02
RM-639
Service Manual Level 1&2
20 Confidential | Copyright © 2011 Nokia | All rights reserved Version 3.0
10. ASSEMBLY INSTRUCTIONS
1) Nokia X3-02 assembly. 2) You must use the Nokia Standard Toolkit version
2.
3) Remove the A-COVER adhesive protective film with
the tweezers.
4) Push the LCD connector through the opening and
lower down the LCD.
5) Press the sides of the LCD to activate the adhesive.
Be careful not to damage the LCD.
6) Remove the UI-FLEX ASSY adhesive protective film.
