Fig. 6
• Position the battery in the special slot on the
Basic Kit (see specific instructions for the Basic
Kit).
• Position the e-box in the relevant housing (Fig.
4). First insert the front part, then press down on
the e-box until both hooks fully click (Fig. 5). To
remove the e-box, press the two sliding hooks at
the same time until the e-box comes out (Fig. 6).
Warning: Turn on the system only after you have put
on the helmet
Warning: Do not leave the helmet exposed to
atmospheric agents without the e-box or the
protection plate provided with the helmet.
Fig. 7
Fig. 8
To prevent the e-box from accidentally coming off the helmet, you can use the “E-box safety block” as
illustrated in (Fig. 7)., being careful to push it all the way in its housing.
To remove the “E-box safety block”, lift the front part as shown in (Fig. 8).
