21
X-804
INSTRUCTIONS FOR USE
2 ASSEMBLY
2.1 Place the visor in the fully open position by positioning the internal teeth B at the
corresponding slots in the left side mechanism (Fig.5).
2.2 Rotate the side spacer ring attached to the visor so that its two rectangular slots
coincide and engage with the corresponding rectangular reliefs on the side mech-
anism attached to the shell (Fig. 5).
2.3 Manually tighten the screw of the mechanism by acting on its folding ange A until
it is completely tightened (Fig. 4).
2.4 Follow the previous operations on the right side of the helmet.
2.5 Close the visor completely.
3 VISOR MECHANISM ADJUSTMENT
The visor mechanism is equipped with a visor clearance adjusting system that ensures
that the visor is lowered effectively against the window trim. This is why the mecha-
nism’s support has an upper and lower reference tooth. The helmet is delivered with
a correctly adjusted system. When using the helmet, regularly check that the visor
adheres perfectly and is in line with the deformable lip of the window trim when it is
lowered all the way. If this is not the case, proceed as follows:
3.1 Disassemble the visor (see instructions above) and check in which position of the
upper C1 and lower C2 reference teeth the mechanism is located (Fig. 6).
3.2 Loosen the two screws D1 and D2 in the visor mechanism using a T10 Torx
wrench.
3.3 Lift the mechanism from its support and move it forwards or backwards according
to the adjustment to be made. Then lower the mechanism into its support so that
the upper C1 and lower C2 adjustment teeth are in the same position.
3.4 Tighten both screws D1 and D2.
3.5 Follow the same steps on the other side of the helmet.
3.6 Assemble the visor (see instructions above).
3.7 Check contact between the visor and the trim.
WARNING
- Check that the mechanisms are working properly. Open and close the visor,
checking that the latter is held in place in its different positions by the mecha-
nisms. If necessary, follow the previous operations mentioned above.
- Do not use the helmet if the visor has not been properly assembled.
- Never remove the side mechanisms from the shell.
- Should any of the side mechanisms fail or be damaged, please contact a Nolan-
group authorised dealer.
(
XFR-03
)
(Available as standard or accessory/spare part)
1 ASSEMBLY
1.1 Disassemble the visor (see instructions above).
1.2 Make sure that the inner surface of the visor is clean and check that the pin adjust-
ment external levers are turned inwards (Fig.7).
1.3 Place the PINLOCK
®
inner visor on the visor.
The silicone prole of the PINLOCK
®
inner visor should be in contact with the
inner surface of the visor.
