Instalation Manual Ver. 240130 8 Nomadic Cooling Co
5. Paint around the edges of the cut roof
opening to prevent rust. You can use any
color rust-preventative paint.
6. Remove tape and clean surface.
7. Remove waterproof gasket from box.
Make sure area/paint is clean, dry and
clear of all debris.
Use alcohol wipes or PrepSol to
remove oil or wax from vehicle roof.
If pacing gasket over a high or uneven
roof surface, remove small amounts of the
14"x14" gasket to match roof contours.
Use bade to cut away gasket
if needed.
Remove gasket adhesive only after
making any necessary cuts. Pace the
gasket sticky side down.
8. Apply polyurethane adhesive seaant (in-
cluded in DIY kit) around 14"x14" gasket.
9. Gently pace AC unit on roof over gasket.
Inner gasket dimension is 14"x14", outer
dimension is 16.25"x16.25". Measure side-
to-side until centered on all four sides.
Be careful not to puncture, rip
or tear the gasket with AC unit’s
mounting bolts.
Do not put adhesive on top of gasket.
Do not damage electrical components
when pacing AC unit.
10. Adhere optional leveling strip behind the
foam gasket.
Exterior Roof
Exterior Roof
URETHANE ADHESIVE
CUTAWAYS FOR ROOF RIDGES
Leveling strip
14” x 14” gasket
Adhesive side
