5 COMPLETING THE INSTALLATION
1. Turn on the power for the UC4+ Control Panel using the switch on the side of its chassis. Ensure that
the display lights up to confirm that the panel has proper +12 volt power.
2. After a moment the panel will display the main operational screen:
↓M 45 M↓
3. For optimal performance, the UC4+ system must calibrate itself to the tractor unit powering the
sprayer hydraulics, which is an automated process.
Performing a RETUNE requires that the sprayer is unfolded and the booms have full range
of moment. This should also be performed on a flat area of ground, over gravel or dirt. Do
not attempt to perform a retune over grass.
4. To initiate the RETUNE process, navigate from the Main Operational Screen to the “RETUNE”
menu, following the instructions below:
• Using the left-hand toggle switch on the UC4+ panel, toggle the switch down towards “Setup”
until ↓RETUNE?↓ appears on the display.
• At this point, answer YES to the panel by toggling the right-hand toggle switch up towards “Yes”.
• The panel will start the RETUNE process. Follow the on-screen prompts.
Additional information concerning the RETUNE procedure may be found in the UC4+
Operator’s Manual and the UC4+ Quick Reference Manual
5. The installation of the UC4+ system is now complete. Refer to the Quick Guide (M01B) for
operation instructions.
