36

ShortCircuitTest
1. Disconnectalltheheightsensors,modules,rollsensorsandpowerfromtheNORACCANbus.Ensure
allcablesandterminatorsareconnectedtogether.
2. Usinganohmmeter,testtheresistanceofallthepincombinationsonthe6‐pinconnector(C01).
3. Ifanincorrectvalue
ismeasured,continuebytestingatthenextconnectionuntiltheproblemcable
isisolated.
Pin# Pin# Value
1 2 OpenCircuit
1 3 OpenCircuit
1 4 OpenCircuit
1 5 OpenCircuit
1 6 OpenCircuit
2 3 OpenCircuit
2 4 OpenCircuit
2 5 OpenCircuit
2 6 OpenCircuit
3 4 75Ω±10Ω
3 5 OpenCircuit
3 6 OpenCircuit
4 5 OpenCircuit
4 6 OpenCircuit
5 6 OpenCircuit
