37



OpenCircuitTest

Theopencircuittestwillapplyvoltagetothecablingandcheckforanyopencircuits.

1. Ensureallthedevicesarestilldisconnectedfromthebus.

2. Reconnectthecablestothecontrolmodule.(C01,battery,display)

3. Turnonthesystempower.

4. Using a

voltmeter, measure the voltage of the following pin combinations at each of the sensor

connections.



Pin# Pin# Value

1 3 0.5to6VDC

1 4 0.5to6VDC

1 6 12±3VDC

2 5 12±3VDC

5. Ifanincorrectvalueismeasured,continuebytestingatthenextconnectionuntiltheproblemcable

isisolated.



 
