5.6. SystemSettings
CalibratingDeadzones
Tip:Performinganautomaticretunewillsetthedeadzoneandgainvalues.
Thedeadzonevaluerelatestothesmallestamountofboommovementthevalvecanproduce.
1. Ensurethesprayerisoverbarelevelsoilorgravel.Thesprayershouldbeatoperatingtemperature
andRPM.
2.
Navigateto:RunScreen‐>Settings‐>Next‐>Setup‐>Valves.
3. Selecttheboomfunction.PresstheDeadzonebutton.
4. Pressandholdthemanual(M)button.
5. Holduntiltheboomstopsmovingandthereadingstabilizes.
6. Thereporteddistanceshouldbe1‐2inches(2‐5cm).
Adjustthedeadzoneuntilthedistanceiswithin
1‐2inches(2‐5cm).
Gains
Thegainvaluerelatestothemaximumspeedoftheboom.
1. Thegain calibrationis dependentonthedeadzonevalue.Beforecalibratingthegain,thedeadzone
valuemustbecorrectlycalibratedforthesamechannel.
2. Ensurethesprayerisoverbarelevelsoilorgravel.Thesprayer
shouldbeatoperatingtemperature
andRPM.
