Norcold 1082 - Start Up Instructions; Lighting and Start Up Instructions; Lighting Instructions - Gas Operation; Start-Up Instructions - AC Operation

AC Electric Malfunction
Do not use if problem occurs on Gas Mode
Is thermostat set
at mid-range or
higher?
NO
YES
Is circuit breaker
or fuse blown?
(AC source to
refrigerator)
YES
NO
Is refrigerator’s
AC power cord
connected to
receptacle?
NO
YES
Is AC voltage
present at the
AC outlet?
NO
YES
Set mode
selection switch
to "Elec" & start
refrigerator.
Connect AC
cord to receptacle
or correct AC
source to recepta-
cle.
Connect AC cord
into receptacle &
start refrigerator.
Reset circuit
breaker/replace
fuse & start
refrigerator.
Set thermostat to
mid-range or
higher and start
refrigerator.
Remove control
panel bracket &
pull controls
forward.
YESYES
Check heater
resistance. If not
within specs.,
replace heater.
Check hot
(smooth) wire
of AC power cord to
the fuse holder.
Replace if needed.
Replace 5 amp
fuse and start
refrigerator.
Is mode
selection switch
in the
AC position?
NO
YES
Is AC voltage
present at the
AC heater?
YES
Is AC voltage to
input of 5 amp
fuse?
NO
NO
Is AC voltage at
output of the
5 amp fuse?
NO
YES
Remove control
panel at front of
the refrigerator.
(Fig. 10 on page 14)
YES
Is AC voltage
at input of
combination
control?
NO
YES
Check black wire
from fuse to
combination
control.
Go to cooling
unit diagnostic
procedures on
page 18.
Is AC voltage at
output of
combination
control?
NO
YES
Replace
combination
control and start
refrigerator.
Specifications
AC Voltage: 108-132 VAC Current Draw: 2.7-2.9 AMPS Heater Resistance: 38-43 OHMS
8
