Owner’s Manual 12
Art 00956
77
78
79
80
CAUTION
!
NOTICE
WARNING
!
WARNING
!
Remove and clean the burner orice:
A dealer or Norcold authorized service center must do this procedure.
To remove and clean the burner orice:
- Close the valve at the propane gas tank(s).
- Open the lower intake vent.
- Push and turn the gas control to the OFF position
- Turn the mode selector to the OFF position.
The burner box cover can be hot. Wear gloves to avoid burns.
- Remove the burner box cover by removing one screw.
To avoid possible propane gas leaks, always use two wrenches to tighten or loosen the gas supply line
connections.
- Remove the are nut from the orice assembly [77] (See Art00956).
- Remove the orice assembly from the burner [78]
When cleaning, do not try to remove the orice [79] from
the orice adapter [80]. Removal will damage the orice
and seal of the orice and can cause a propane gas leak.
Leaking propane gas can ignite or explode and result in
dangerous personal injury or death. Do not clean the
orice with a pin or other objects.
- Clean the orice assembly with alcohol only.
- Using a wrench, assemble the orice assembly to the burner.
- Assemble the are nut to the orice assembly.
- Tighten the are nut by hand.
- Hold the orice assembly securely and, using a wrench, tighten the are nut 1/4 revolution only.
- Examine all of the gas connections for leaks.
Remove the Refrigerator
A dealer or Norcold authorized service center must do this procedure.
The rear of the refrigerator has sharp edges and corners. To prevent cuts or abrasions when working on the
refrigerator, be careful and wear cut resistant gloves.
1. Close the valve at the propane gas tank(s).
To avoid possible gas leaks, always use two wrenches to tighten or loosen the gas supply line at the
manual shutoff valve of the refrigerator.
2. Open the lower intake vent and remove the gas supply line from the 3/8 inch male are tting of the refrigerator.
CAUTION
!
NOTICE
WARNING
!
