Installation Manual 6
1. Select Wire Size
-The refrigerator power supply can be run with either single cables or two sets of cables. Reference the table to determine the
maxium wire length for a given wire size and wiring method.
Cable Size Acceptance
Taille du câble Acceptation
Câble
unique
Négatif
& Positif
AWG
Longueur de
câble pieds max
nombre de brins de
câble
10
0-15
>=19
8
0-20
>=19
8
0-25
>=133
6
0-40
>=133
6
0-45
>=266
Deux
négatifs
et deux
positifs
10
0-30
>=19
8
0-45
>=19
2. To protect the DC power supply wiring, install a fuse or circuit breaker in the positive (+) DC power supply wire as close to the battery
or power source as possible. The fuse should be sized according to the ANSI/RVIA Standard for Low Voltage Systems in Conversion
and Recreational Vehicles.
- There is a 15 amp automotive fuse in the DC circuit at the refrigerator power supply leads to protect the controls of the refrigerator.
This amp should only be replaced with a 15 amp automotive fuse.
3. Connect the DC power supply wires.
If the DC power supply leads are attached incorrectly, the refrigerator will not operate.
-Connect the rst positive (+) DC power supply lead to the positive (+) terminal identied as circuit 1.
-Connect the rst negative (-) DC power supply lead to the negative (-) terminal identied as circuit 1.
If 2 sets of power cables are used:
-Connect the second positive (+) DC power supply lead to the positive (+) terminal identied as circuit 2.
-Connect the second negative (-) DC power supply lead to the negative (-) terminal identied as circuit 2.
- Make sure that:
- Each DC power supply lead is attached to the correct polarity wire of the refrigerator power supply.
- The chassis or the vehicle frame is not used as one of the conductors.
- The DC power supply wires including the fuses are routed directly from the power source to the refrigerator.
- The wire connections must be clean, tight and free of corrosion. If any of these items are not correct, a voltage drop to the
refrigerator will occur.
The voltage drop will decrease the cooling performance of the refrigerator. Disconnect the positive (+) DC
power supply wire from the battery before you do a “fast charge” of the battery. Failure to disconnect the
positive (+) power supply wire from the battery during a “fast charge” can cause damage to the refrigerator
or other DC appliances.
Allow the refrigerator to stand upright for 30 minutes before being powered on.
Connect the Electrical Components
NOTICE
CAUTION
!
CAUTION
!
