Norcold N64X - Wiring Diagrams and Pictorials; Wiring Diagram and Pictorial

Owner’s Manual 20
3. Install the screws in the mounting ange at the rear of the refrigerator.
4. Put the plastic plugs into the mounting anges of the refrigerator.
To avoid possible propane gas leaks, always use two wrenches to loosen and tighten the gas supply line
connections.
5. Attach the gas supply line to the bulkhead tting of the refrigerator.
6. Open the valve at the propane gas tank(s).
Do not allow the leak checking solution to touch the electrical components. Many liquids are electrically
conductive and can cause electrical shorts and in some cases, re.
7. Examine the gas supply line for leaks.
8. Connect the DC wiring to the refrigerator:
- Connect the DC wires to the refrigerator.
- Install the DC fuse or connect the DC wiring to the battery or the converter.
9. Connect the black AC power cord and the white ice maker AC power cord (model N843-IM only) to the receptacle.
Wiring Diagram and Pictorial
The parts in the wiring pictorial are (See Art01875):
The parts in the wiring diagram are (See Art01876):
AC heater .................................................................................................................................................................................................A
Light ......................................................................................................................................................................................................... B
Thermister ............................................................................................................................................................................................... C
Gas valve................................................................................................................................................................................................. D
Igniter....................................................................................................................................................................................................... E
Divider heater ...........................................................................................................................................................................................F
Temperature switch (optional) ................................................................................................................................................................. G
Temperature switch (optional) ................................................................................................................................................................. H
Fan (optional) ............................................................................................................................................................................................I
Ice maker water line heater (optional) ......................................................................................................................................................J
DC heater (optional) ................................................................................................................................................................................ K
Chassis ground.........................................................................................................................................................................................L
DC board (optional) .................................................................................................................................................................................M
Door switch .............................................................................................................................................................................................. N
Temperature switch ..................................................................................................................................................................................P
Switched 12 VDC .....................................................................................................................................................................................1
Fused continuous 12 VDC........................................................................................................................................................................2
Communications ....................................................................................................................................................................................... 3
Display ground..........................................................................................................................................................................................4
Auxiliary ground ........................................................................................................................................................................................ 5
Auxiliary +12 VDC ....................................................................................................................................................................................6
Divider +12 VDC .......................................................................................................................................................................................7
Gas valve +12 VDC .................................................................................................................................................................................. 8
5 Amp fuse DC .......................................................................................................................................................................................F1
8 Amp fuse AC ........................................................................................................................................................................................F2
30 Amp fuse DC ....................................................................................................................................................................................F3
WARNING
!
WARNING
!
