Owner’s Manual 13
Do not try to remove the orice [79] from the orice adapter [80] when cleaning. Removal will damage
the orice and seal of the orice and can cause a propane gas leak. Leaking propane gas can ignite or
explode which can result in dangerous personal injury or death. Do not clean the orice with a pin or
other objects.
- Clean the orice assembly with air pressure and alcohol only.
- Using a wrench, assemble the orice assembly to the burner.
- Assemble the are nut to the orice assembly.
- Examine all of the connections for gas leaks.
- Clean the burner box.
- Assemble the burner box cover.
- Assemble the drip cup.
Remove the Refrigerator
Your dealer or Norcold authorized service center must do this procedure.
The rear of the refrigerator has sharp edges and corners. To prevent cuts or abrasions when working on the
refrigerator, be careful and wear cut resistant gloves.
1. Close the valve at the propane gas tank(s).
To avoid possible propane gas leaks, always use two wrenches to loosen and tighten the gas supply line
connections.
2. Remove the AC power cord(s) from the receptacle.
3. Remove the DC wiring from the refrigerator:
- Put a mark on the DC wires so you can put them back in the correct location.
- Remove the DC fuse or remove the DC wiring from the battery or the converter.
- Remove the DC wires from the refrigerator.
4. Open the lower intake vent and remove the gas supply line from the bulkhead tting of the refrigerator.
5. Remove the plastic plugs from the mounting anges of the refrigerator.
6. Remove the screws from the mounting ange at the rear of the refrigerator.
7. Remove the screws from the upper and lower mounting anges on the front of the refrigerator.
8. Remove the refrigerator from the opening.
WARNING
!
WARNING
!
CAUTION
!
